Stainless U-Beam Channel Steel
Stainless U-beam channel steel (also called stainless steel channel bar) is a U-shaped structural profile with a vertical web and two horizontal flanges, made from corrosion-resistant stainless steel. It offers a balance of strength, lightweight design, and durability, making it ideal for applications where rust resistance and structural integrity are critical.
Product Parameters

Features


Common stainless steel grades used:

304/304L – General-purpose, good corrosion resistance.

316/316L – Superior resistance to chlorides (marine/chemical environments).

Duplex (2205/2207) – High strength & pitting resistance.

430 – Cost-effective but less corrosion-resistant.


2. Types & Dimensions

Standard U-Channel: Symmetrical flanges (e.g., 40×20×3mm).

Custom Profiles: Uneven flanges or reinforced thickness.


Common Sizes:

Depth (Web Height): 20mm – 300mm

Flange Width: 10mm – 100mm

Thickness: 1mm – 20mm


3. Advantages

Corrosion Resistance – No rust, ideal for humid/chemical environments.

High Strength-to-Weight Ratio – Strong yet lighter than carbon steel.

Easy Fabrication – Can be welded (TIG/MIG), cut, and bent.

Aesthetic Appeal – Polished or brushed finishes for architectural use.


Chemical composition

GradeC (≤)Si (≤)Mn (≤)P (≤)S (≤)CrNiMoOther elementsType
2010.1515.5-7.50.060.0316-183.5-5.5-N≤0.25Austenite   (low nickel)
3030.15120.20.15↑17-198-10-Se/S   improves machinabilityFree-cutting   austenite
3040.080.7520.0450.0318-208-10.5--Austenite
304L0.030.7520.0450.0318-208-12-Ultra-low   carbon (resistance to intergranular corrosion)Austenite   (low carbon)
3050.120.7520.0450.0317-1910.5-13-High   nickel (reduces cold work hardening)Austenite
3090.2120.0450.0322-2412-15-High   temperature oxidation resistanceAustenite   (heat resistant)
309S0.08120.0450.0322-2412-15-Low   carbon version 309Austenite   (heat resistant)
310S0.081.520.0450.0324-2619-22-Ultra-high   temperature resistance (1150℃)Austenite   (heat resistant)
3160.080.7520.0450.0316-1810-142.0-3.0Pitting   resistance (Mo)Austenite   (corrosion resistant)
316L0.030.7520.0450.0316-1810-142.0-3.0Ultra-low   carbon (resistance to intergranular corrosion)Austenite   (corrosion resistant)
316Ti0.080.7520.0450.0316-1810-142.0-3.0Ti≥5×C   (stabilization and anti-sensitization)Austenite   (stabilized)
3210.080.7520.0450.0317-199-12-Ti≥5×C   (resistance to intergranular corrosion)Austenite   (stabilized)
3470.080.7520.0450.0317-199-13-Nb+Ta≥10×C   (stabilization)Austenite   (stabilized)
4090.08110.0450.0310.5-11.70.5-Ti   0.15-0.5 (stabilization)Ferrite   (auto exhaust)
4100.15110.040.0311.5-13.50.75--Martensite   (knife)
4200.15↑110.040.0312-140.75-High   carbon (higher hardness)Martensite   (scalpel)
4300.120.7510.040.0316-180.75--Ferrite   (decorative)
904L0.02120.0450.03519-2323-284.0-5.0Cu   1.0-2.0 (acid resistance)Super   austenite




Mechanical properties

GradeTensile Strength   (MPa)Yield Strength   (MPa)Elongation (%)Hardness (HB)Impact toughnessOther   Features
201520-750≥27540-55≤230mediumLow   nickel and high manganese, fast cold work hardening
303500-700≥19035-50≤200LowEasy   to cut, corrosion resistance slightly lower than 304
304515-690≥20540-60≤200highGeneral   austenite, non-magnetic
304L485-655≥17045-60≤200highLow   carbon, intergranular corrosion resistance
305500-700≥18050-60≤200highHigh   nickel, low cold work hardening rate
309515-690≥20540-50≤200mediumHigh   temperature oxidation resistance (≤1000℃)
309S515-690≥20540-50≤200mediumLow   carbon version of 309, anti-sensitization
310S515-690≥20540-50≤200mediumUltra-high   temperature resistance (≤1150℃)
316515-690≥20540-60≤200highContains   Mo, pitting and creep resistance
316L485-655≥17045-60≤200highUltra-low   carbon, intergranular corrosion resistance
316Ti515-690≥20540-60≤200highTi   stabilized, anti-sensitization
321515-690≥20540-55≤200highTi   stabilized, high temperature resistance (800℃)
347515-690≥20540-50≤200highNb   stabilized, anti-sensitization
409380-550≥17020-30≤180LowFerrite,   automotive exhaust system
410480-620≥27520-25≤200LowMartensite,   heat treatable (HRC≥50)
420550-750≥34515-20≤230LowHigh   carbon martensite, HRC up to 55
430450-600≥20520-25≤200LowFerrite,   decorative use
904L490-690≥22045-50≤200highSuper   austenite, strong acid resistance

Common Applications


Construction: Framing,   supports, brackets.
    Marine & Offshore: Shipbuilding,   dock structures.
    Industrial: Conveyor   systems, machinery guards.
    Architecture: Handrails,   decorative trims, façades.
    Food & Pharma: Hygienic   equipment supports.


Product Display

H-type steel.jpg


Product Application

carbon steel.jpg

Product Packaging


Factory Display
  • 11.jpg
  • 10.jpg
  • 9.jpg
  • 8.jpg
  • 7.jpg
  • 6.jpg
  • 5.jpg
  • 4.jpg
  • 3.jpg
  • 2.jpg
  • 1.jpg
  • 12.jpg
FAQ

Q:Can I get samples before order ?

A:Yes, of course. Usually our samples are free,we can produce by your samples or technical drawings.

Q:Can I go to your factory to visit?

A:Of course, we welcome customers from all over the world to visit our factory.

Q:How can I get a quotation from you ?

A:You can leave us message, and we will reply every message in time. Or we may talk on line.

Q:What product information do I need to provide?

A:You need to provide the grade, width, thickness, coating and the number of tons you need to purchase.

Q:Does the product have quality inspection before loading?

A:Of course, all our products are strictly tested for quality before packaging, and unqualified products will be destroyed.we accept the third party inspection absolutely.

Q:What are the advantages of your company?

A:(1)More Than 30 year's Experience

(2)The company is a modern steel enterprise group integrating precision manufacturing, spot warehousing, international logistics, and product deep processing.

(3)World-class production equipment, product quality that meets international certifications, and timely and thoughtful after-sales service

(4)Never stop product research and development and innovation to create high-quality products that meet the global standards.

(5)Integrity business philosophy, the highest quality products, the most reasonable prices, and a global marketing network.

Q:How do we trust your company?

A:We specialise in steel business for years as golden supplier on Alibaba, headquarter locates in liaocheng, Shandong province, you are welcome to investigate in any ways, by all means, you could place an order in Alibaba with trade assurance which could secure your payment.
