A252 Seamless&Welded Pipe Piles
ASTM A252 is the standard specification for nominal-wall cylindrical steel pipe piles, where the cylinder acts as a permanent load-bearing member or shell to form a cast-in-place concrete pile. The ASTM A252 specification has three grades: Grade 1, Grade 2, and Grade 3, of which Grade 2 and Grade 3 are commonly used materials.
+8618560151732
Contact Us
Product Parameters

Carbon Steel: Properties, Production, Examples and Applications


Carbon steel is an iron-carbon alloy, which contains up to 2.1 wt.% carbon. For carbon steels, there is no minimum specified content of other alloying elements, however, they often contain manganese. The maximum manganese, silicon and copper content should be less than 1.65 wt.%, 0.6 wt.% and 0.6 wt.%, respectively.


Types of carbon steel and their properties


Carbon steel can be classified into three categories according to its carbon content: low-carbon steel (or mild-carbon steel), medium-carbon steel and high-carbon steel . Their carbon content, microstructure and properties compare as follows:


Carbon content (wt.%)MicrostructurePropertiesExamples
Low-carbon steel< 0.25Ferrite, pearliteLow hardness and cost. High ductility, toughness, machinability and weldability
Medium-carbon steel0.25 – 0.60MartensiteLow hardenability, medium strength, ductility and toughness
High-carbon steel0.60 – 1.25PearliteHigh hardness, strength, low ductility


Carbon Steel Description


Grade:


1)GB: Q195, Q215, Q235A, Q235B, Q235C, Q235D, Q255A, 255B, Q275, Q295A, Q295B, Q345B, Q345C, Q345D, Q345E, Q390A, Q390B, Q390C,Q390D, Q390E, Q420, Q420B, Q420C, Q420D, Q420E, Q460D, Q460E, Q500D, Q500E, Q550D, Q550E, Q620D, Q620E, Q690D, Q690E


2)EN: S185,S235JR, S275JR, S355JR, S420NL, S460NL S500Q, S550Q, S620Q, S690Q


3)ASTM: Grade B, Grade C, Grade D, A36, Grade 36, Grade 40, Grade42, Grade 50, Grade 55, Grade 60, Grade 65, Grade 80


4)JIS: SS330, SPHC, SS400, SPFC, SPHD, SPHE



PRODUCT DETAILS


A252  Seamless&Welded Pipe Piles Description
The  chemical composition of A252 steel pipe mainly consists of iron, carbon,  silicon, manganese and other elements, of which the carbon content is low,  only about 0.2%. A252 steel pipe piles has excellent mechanical properties,  high strength and toughness, tensile strength is generally between  400-550MPa, and has good low-temperature toughness. A252 seamless welded pipe  piles play an important role in petroleum, chemical industry, machinery,  construction and other fields.


Product   Parameters
Product NameA252 Seamless&Welded Pipe Piles
StandardEN/DIN/JIS/ASTM/BS/ASME/AISI etc.
Outer DiameterSeamless: 1/4"-36"Welding: 21.3mm-3620mm
Round Tube: 1/2"-10"Square   Tube/Rectangular Tube: 15x15mm-400x600mm
Wall   ThicknessSeamless: 1.25mm-50mmWelding: 1.65mm-65mm
Length3-12 meters, Support customization
Surface ProcessBright, Polished, Black
Other   ServicesMachining(cnc), Centerless Grinding(cg), Heat   Treatment, Annealing, Pickling, Polishing, Rolling, Forging, Cutting,   Bending, Small Machining, etc.
Chemical  Composition
Seamless and ERW Welded PipeMaximum  Phosphorus Content 0.050%
Mechanical  Properties
A252Tensile  Strength psi(Mpa)Yield  Strength psi(Mpa)
Grade150,000(345)30,000(205)
Grade260,000(415)35,000(240)
Grade366,000(456)45,000(310)
Scope of  Application
Pile  foundation, micropile, manufacturing, bridge, structure, etc.


Product Display
Product Application

应用 (2).jpg

Product Packaging



Factory Display
  • 11.jpg
  • 10.jpg
  • 9.jpg
  • 8.jpg
  • 7.jpg
  • 6.jpg
  • 5.jpg
  • 4.jpg
  • 3.jpg
  • 2.jpg
  • 1.jpg
  • 12.jpg
